مميزات خاصة

Onboard 4 channel 817 are independent: can achieve different voltage control at then same time
4-way 817 optocoupler driving port signal voltage:3.3-24V; Output voltage range: 3.6-30V(The output current depends on the specific situation but not over 10MA. When the total power is fixed, the voltage and current are inversely proportional)
4 way 817 optocoupler to achieve the control signal and the control signal isolation, you can directly use the microcontroller or other devices IO port to achieve voltage isolation control, you can achieve a small voltage control, the control side can be an external transistor MOS tube or different voltage levels Of the device interface
PC817 module jumper cap can achieve output port is high potential or pull down output
If it is a pulse signal, please note that the limit of 817 is below 3KHZ. If the control signal is greater than 3KHZ, please do not use this module, it will not work properly.

وصف

Driving port signal voltage:3.6-24V
Output port voltage port:3.6-30V
Jumper cap can achieve output port is high potential or pull down output
Onboard 4-channel 817 are independent: can achieve different voltage control at then same time

This module is used when it is necessary to isolate the control in actual work and voltage conversion.
for the friend of the single-chip or PLC, it is only necessary to judge when the output port is low.
The photoelectric isolation has strong anti-interference ability， and the combination control of many different devices can be realized later, such as triode, MOSt u be, and small power relay module.

Package include:
3 x PC817 4-channel optocoupler isolation board

NOTE:
The input port is shared with GND
The output ports are independent of each other
It is optocoupler output.V and G will be connected after input valid signa in input port
