Terminal Fuse 80A Marine Rated Battery Fuse (MRBF) 58V DC Max IP66 Waterproof

Specification:
Rated Current: 80A Rated Voltage: 58VDC Ingress Protection: IP66 Ignition Protected: Per SAEJ1117 Interrupt Capacity: 10000A @ 14VDC, 5000A @ 32VDC, 2000A @ 58VDC Maximum Torque: 12Nm (1224Kgf-cm) (106 in-lbs) Material: body, insulating material ceramic; housing & cover, UL-rated 94V0 thermoplastic; fuse, copper alloy (nickel plated), ring terminals, tin plated Features: high load capacity, ignition protection, visible fuse, security, easy to install Notice: DO NOT mount fuse directly onto battery post. Fuses should be mounted on the MRBF terminal fuse block. Application:

💡Full range circuit protection for automotive and marine applications.
The breaking capacity meets the requirements of conventional vehicle batteries and 12V, 24V and 42V electrical networks.
10,000 AIC at 14V DC satisfies ABYC requirements for DC Main circuit protection on large battery banks.

💡Compact, high-amp fuse appropriate for DC Main, inverters, windlass and bow thruster circuit protection.
Designed to provide high current protection in tight space constraints.
Ignition protected when used with MRBF Terminal Fuse Blocks.
Isolated stud design uses standard M8 hardware and permits stacking of terminals.

💡Suitable for main and auxiliary circuit protection such as alternator outputs, starter motor inputs and accessory circuits.
Alleviates having to make up a short wire to connect to a standard fuse block to the battery.

Package Included:
1 x MRBF Battery Terminal Fuse 80A
