Featuring 12N14P high torque design, strong thrust, more powerful than other ordinary brushless motors, high working efficiency
Precisely balanced rotor is stable with high speed, ensure the motor high-speed running without shake and has the best reliability and the largest RPM
High purity copper windings maximize efficiency, 42SH magnets and NMB bearing, good insulation and heat resistance
Motor KV 2200KV, shaft size 3.17 x 41mm, motor mount 16 x 19mm (M3*4), which is compatible with 7~8 inch propeller
The motor battery is 2~3S lipo, which is widely use in RC aircraft, drone, fixed wing, helicopter, plane, multicopter and so on

Specification:
Battery: 2-3S Lipo
Motor Weight:50g
Motor Size: 27.7*26mm
Shaft Size: 3.17*41mm
Motor Mount: 16*19mm(M3*4)

D2826-2200KV
Max pull : 960g
Volts: DC7.4~11.10V
Suggested ESC: 30A~40A
Maximum Power: 342W
Suggested Prop: 7~8 inch prop

D2826-1400KV
Max pull : 780g
Volts: DC7.4~11.10V
Suggested ESC: 30A~40A
Maximum Power: 205W
Suggested Prop: 7~9 inch prop

D2826-1000KV
Max pull: 660g
Volts: DC7.4~11.10V
Suggested ESC: 30A~40A
Maximum Power: 150W
Suggested Prop: 10~11 inch prop

D2826-930KV
Max pull: 645g
Volts: DC7.4~11.10V
Suggested ESC: 30A~40A
Maximum Power: 130W
Suggested Prop: 11~12 inch prop
