Overview:
The LNK-DC-P24G is a low cost and high efficiency solution for those requiring Passive Power over Ethernet from a 36-72VDC voltage source. They have an integrated POE injector to apply the power and data output to the CAT5/6 Ethernet cable. The output voltage is regulated and protected.
Features:
Input Voltage 36-72VDC; Output 24VDC (Passive)
Integrated Gigabit PoE Inserter; High Power 24W
High Efficiency > 85%; Nominal Frequency 50/60KHz
Support 10/100/1000Base-T, Half/Full-duplex
Over-Voltage/Load/Temperature & Short Circuit protections
Plug & Play, no configuration required
Safe and Reliable Power to WLAN Access Points
Specifications:
Connector: LAN: 1 x RJ-45 STP, “Data” Input Port
POE: 1 x RJ-45 STP, “Data + Power” Output Port
Cabling: 10/100/1000Base-T, Cat5 or above
Input Voltage Range: 36-72V DC
Output Voltage: DC 24V, 1.0A
Power Consumption: 24W max.
Power Pin Assignment: Pin 1,2 / 4,5 (+), Pin 3,6 / 7,8 (-)
Processing Type: Forward; Half-duplex, Full-duplex
Forward Filter Rate: 1,488,000pps (1000Mbps)
Maximum Distance: Cat. 5/5e/6 up to 100m (328ft)
Casing Material: Plastic Case
Operating Temperature: -10°C to 50°C (14°F to 122°F)
Storage Temperature: -20°C to 70°C
Mounting Option: Desktop
Dimensions (W×D×H): 122 x 60 x 40mm
Weight: 0.35Kg
Ethernet Standards:
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
