PCIE to Dual RS232 Serial Adapter Card with WCH382L Chip for in Kuwait PCIE to Dual RS232 Serial Adapter Card with WCH382L Chip for in Kuwait PCIE to Dual RS232 Serial Adapter Card with WCH382L Chip for in Kuwait PCIE to Dual RS232 Serial Adapter Card with WCH382L Chip for in Kuwait PCIE to Dual RS232 Serial Adapter Card with WCH382L Chip for in Kuwait PCIE to Dual RS232 Serial Adapter Card with WCH382L Chip for in Kuwait

PCIE to Dual RS232 Serial Adapter Card with WCH382L Chip for

KWD 5
– 1 +

مميزات خاصة

  • Dual Port Support: This PCI-E to Dual Serial Adapter delivers two independent 9-pin RS-232 ports supporting simultaneous communication at up to 230.4 Kbps each, enabling connection of multiple devices such as barcode scanners, POS terminals, industrial sensors, and modems without port conflict or performance loss.
  • PCI-E x1 Compatibility: Designed with a standard PCI Express x1 interface, this card fits seamlessly into any available PCIe slot—including x4, x8, and x16 motherboards—ensuring broad compatibility across desktop PCs, workstations, and embedded systems used in retail, banking, and automation environments.
  • Broad OS Support: Fully supports DOS, 2000 through 8 (32/64-bit), Server 2003–2008, and mainstream distributions out of the box, with plug-and-play installation and stable driver availability—no third-party software or complex configuration required.
  • Industrial UART & FIFO: Built around the WCH382L chip, it implements 16C550-compatible UART logic with 256-byte hardware FIFO buffers per port, enabling reliable high-speed data transfer, robust RTS/CTS and XON/XOFF control, and full modem signal support (TxD, RxD, DTR, , DCD, etc.).
  • Plug-and-Play Ready: Includes a driver CD and automatic BIOS-assigned I/O address and IRQ handling—no manual resource configuration needed. The low-profile design fits most ATX and micro-ATX cases, and the card operates silently without external power or cooling requirements.

وصف

Specification:
Description:
This PCI Express serial card, is specially designed for POS and ATM applications. The product with WCH382L chip supports a variety of mainstream operating systems, including and . In addition, the extended 2 rs-232 serial ports can support the communication rate of 230.4 Kbps, and provide modem control signals to ensure compatibility with all kinds of external serial port devices. Since the card is PCI Express "x1", it can be installed on various PCI Express slots (including 4x 8x16x).
Features:
Two (2) 9-pin RS-232 serial ports.
PCI Express x1 interface (will also work on PCI-E x4, x8, x16 slot).
Compliant with PCI Express specification Revision 1.1.
PCI Express single-lane (x1) bus bandwidth 2.5 Gbps.
Support DOS, 8/7 / Vista/ / 2000 / Server 2003-2008 32/64-bit, operating systems.
Serial Interface (RS232):
with industrial standard 16C450/16C550 UART
On-Chip 256-bit depth FIFOs in Transmit, support H/W, S/W control
Data transmission rate of each serial port can be up to 250Kbps
Baud rate: 230.4 Kbps
Serial communication parameter data bits: 5, 6, 7, 8
Stop bit: 1, 2
Parity: None, Even, Odd, Space,
control: RTS/CTS, XON/XOFF
I/O address: Assigned by the BIOS
IRQ: Distributed by the BIOS
Serial signal RS - 232: TxD, RxD, RTS, CTS, DTR, , DCD, GND
Specifications:
Chip: WCH382L
Type: PCI-E to Serial Interface Card
Interface: 1 x PCI-E, 2 x Serial
Operating Systems: Support DOS, 8/7 / Vista/ / 2000 / Server 2003-2008 32/64-bit, operating systems.
Package weight: 101g
Package Included:
1x PCI-E to Dual Serial Port Controller Card
1 x Drive CD
Package List
Note
