★Specifications★
⚠ Camera
✔Image Sensor: 1/3″ progressive scan CMOS

✔Min. illumination: 0.01 lux @ (F1.2, AGC ON), 0 lux with IR

✔Shutter time: 1/3s ~ 1/100,000s
✔Lens: 2.8 – 12mm @ F1.6
✔Day & night: IR cut filter with auto switch
✔IR range: UP to 150ft

✔Digital noise reduction: 3D DNR
✔Wide dynamic range: 120dB True WDR

⚠ Compression Standard
✔Video compression: H.264 / H.264+ / H.265 / H.265+ / MJPEG
⚠ Image
✔Max. Image Resolution: 6MP CMOS, 3072 x 2048

✔Frame rate: 20fps (3072 × 2048), 30fps (2560×1440)

✔BLC: Yes, zone configurable

⚠ Interface
✔Alarm: 1/1
✔Audio: 1/1
⚠ Network
✔Network storage: NAS

✔System compatibility: ONVIF, PSIA, CGI

✔Security: User Authentication, reset button, flickerless, dual stream, heartbeat, mirror, watermark

✔Protocols: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos

✔Communication interface: 1 RJ45 10M / 100M Ethernet interface
⚠ General
✔Operating Temperature: -30 °C ~ 60 °C (-22 °F ~ 140 °F)
✔Humidity: 90% or less (non-condensing)

✔Power supply: 12 VDC +/- 10%, PoE (802.3af)

✔Power Consumption: Max,18W

✔Protection Level: IP67, IK10

✔Dimensions: ∅5.67″ x 13.10″

✔Weight (Approx.): 4 lbs
