558 :
Magnification: 1 X
Objective Lens Diameter : 0.85 in
Eye Relief : Unlimited
Focus Magnification Type : Fixed
Type Illuminated: 20 level brightness red and green reticle to provide maximum flexibility in different lighting conditions
Illumination Type : Reflex
Illumination Reticle Color : Red and Green Dot
Brightness Settings : 10
Adjustment Click Value : 0.5 MOA
Field of View, Linear : 30 yds at 4 in
Resettable windage and elevation adjustment
Height adjustment and view of the side
Eevation adjustment and view of the side of Leverage
Easy to install and setup, Integrated 5/8" 20mm Rail, with built-in quick detachable, Fits any 20mm Rail
Material: Aluminum Alloy Aircraft Grade
Lens Material : Optics Glass
Lens Finish : Fog resistant internal optic
Optical Coating : Anti-Reflection coating on external surface
Finish : Anodizing Coating
Shockproof、Fogproof and Weatherproof Materials
Length/Width/Height : 3.5 in/2.4 in/2.8 in
Accessories: Scope Lens Cover, Lens Cleaning Cloth
Net Weight: 265g
Function Key:
Up Arrow Button: Power on and increase brightness
Down Arrow Button: Power on and reduce glare
Up and Down Arrow Keys: off, pressing the keys simultane
Push NV Button: Reticle Color Switching ( Red / Green )
558(NV Compatible):
More realistic appearance;
Smaller parallax (parallax-free);
Clear reticle with uniform brightness. In bright environments, the red dot remains clear, ensuring accurate aiming.
Made from 7075 aluminum, fully restoring the original details, and capable of withstanding 800g of recoil.
Suitable for AIRSOFT and GBBR.
The lens is exceptionally clear with high light transmission, no mirror effect, and will not reflect your face or other objects. The housing is hard anodized, and the red dot is the 558 with NV functionality, compatible with NVG.
G33X:
Magnification Fixed: 3 X
Eye Relief: 2.2" (55.8mm)
Field of View: 7.3 degrees
Length/Width/Height:3.9"(99mm)/2.2” (55.9mm)/3.3” (83.9mm) With Spacer
Weight: 11.2oz (317.5g) With Mount
Temperature:-40to 140 F(-40 to 60C)
Waterproof(Water-Resistant): 33ft.(10m)
Sealing: Fogproof(Fog-resistant) internal Optics
Excellent Surface Treatment: Non reflective / Rubber coated
Color/Finish: Non reflective black with Hard Coat Anodized Finish.
Optical Axis Adjustment: Internal adjustment
Height: 1.18"(30 mm)Clears common low profile flip up rear iron sights
Switch Orientation: Ambidextrous mount Flip Orientation to allow left or right fip
Rail Interface: Universal interface, with Quick Detach lock
Magnifier Interface: User configurable height with quick detach mount
G43X:
Fixed Magnification 3X
Water Resistance:33 ft. (10 m)
Mount:1″ Weaver or MIL-STD-1913 rail
Eye Relief:2.6″
Field of View: 7.5Degree
Overall Length:2.9″
Material: Aluminum alloy
Sealing Fog resistant internal optics
G45:
Magnification: 5X
Objective Lens Diameter: 25mm
Eye Relief: 2.6 inch
Linear Field of View: 23.3feet @ 100 yds
Angular Field of View: 7.28 degrees
Material: 6063 all-aluminum alloy structure
Appearance size: 100*50*80MM
Net weight: 334.5G
Gross weight: 460G
Glass: Multilayer Broadband Green Film Glass
Bracket Type: Side Switch Quick Release Bracket, 20mm Picatinny Rail Weaver
Fast Magnifier Scope Mount:
Specifications:
Optical Centerline Height: 2.26"
Net Weight: 131.6g/4.64 oz.
Features:
Made by 6068 AL. CNC tech,Surface oxidation treatment
The mount component is made of steel
W/ 21mm Picatinny Rail QD Mount
Create a 2.26" optical centerline from the rail for most optics
Compatible With G33,G43,G45,V3XM,V6XM,VMX-3T,VMX-3T, Micro 3X, Micro 6X ,3X MAG-C,Juliet 3X, Juliet 4X, Juliet Micro 3X
Red Dot Scope Riser Pic Mount:
1. Hard-anodized Machined Aluminum Construction.
2. Optic Mount Can Raise a Height for Your Sight.
3.Fit for 553 551 552 558 556 etc Red Dot Reflex Sight
Specification:
MATERIAL: Aluminum
COATING:Type III Hardcoat Anodized
All Direct-to-Rail Mounted Optics. Optimized for Lower 1/3 Height Optics.
It comes standard with a two cross bolt rail clamp and is compatible with the QD Lever
