PCIe 3.0 x8 to 4-Port M.2 NVMe RAID Expansion Card in Kuwait PCIe 3.0 x8 to 4-Port M.2 NVMe RAID Expansion Card in Kuwait PCIe 3.0 x8 to 4-Port M.2 NVMe RAID Expansion Card in Kuwait PCIe 3.0 x8 to 4-Port M.2 NVMe RAID Expansion Card in Kuwait PCIe 3.0 x8 to 4-Port M.2 NVMe RAID Expansion Card in Kuwait PCIe 3.0 x8 to 4-Port M.2 NVMe RAID Expansion Card in Kuwait PCIe 3.0 x8 to 4-Port M.2 NVMe RAID Expansion Card in Kuwait

PCIe 3.0 x8 to 4-Port M.2 NVMe RAID Expansion Card

KWD 111.500
ماركة
Generic
وزن
137 g
– 1 +

مميزات خاصة

  • Developed based on the Marvel 88NR2241B0 controller; Compliant with PCIe 3.0 specifications and compatible with PCIe 1.0/1.1/2.0;
  • Supports PCIe NVMe protocol;
  • Supports RAID 0, RAID 1, JB0D;
  • Supports SSDs of 2242, 2260, and 2280mm;
  • Supports high-resolution graphics, as well as point-to-point transmission and multicast, to achieve maximum performance.
  • Technical Specifications: Model 2241-4IR Bus type PCI Express 3.0 x8 Main control chip Marvel 88NR2241B0 Interface type M.2 Number of interfaces 4 Transmission rate 64Gb/s No load power consumption 13.344W Full load power consumption 19.32W RAID RAID 0, RAID 1, JBOD Equipment connector 4-M.2 Host bus PCIe x8, compatible with x16
  • operating system Windows 10 /11 Windows Server 2012/2016/2019 /2022 RHEL/Centos7.6 /7.9 /8.2 /8.3 Deepin 15.11 /20 /20.6 /20.9 Ubuntu 18.04.5 /20.04.1/22.04.3 SUSE 12.5/15 SP4 VMwre ESXi 6.5/6.7/7.0 ZTE's new pivot 3.2.2/5.0.5 Red Flag Asianux Operating System V7.0 Galaxy Kirin V10 Winning the bid for Kirin 7.6 Zhongke Fangde Desktop Operating System 4.0 Zhongke Fangde Server Operating System Yiming Operating System Open source Kirin 0.7.5
  • Working environment Working environment temperature: 5 ℃ to 50 ℃ (41 ℉ to -122 ℉) Storage temperature -25 ℃ to -70 ℃ (-13 ℉ to -158 ℉) Storage temperature: 90% non condensing relative humidity at 35 ℃ physical properties PCB size (unit: mm) 209.46 * 110.38 * 1.6 Packaging size (unit: mm) 222 * 147 * 28 Packaging Details Packing List 1- PCI Express NVMe Array Card 1- Full height baffle (default 3U finished installation) Paper box+anti-static bag

وصف

Product Overview 2241-4IR is a PCI Express 3.0 x8 to 4-port M.2 developed based on the Marvel 88NR2241B0 main control solution NVMe array card. It expands the maximum storage space of four M.2 SSDs through scalable, high bandwidth, and non blocking interconnection, connecting to each other Various graphic applications, including servers, storage, communication, and graphic platforms. It has been optimized to support high-resolution graphics while also supporting peer-to-peer support Traffic and multicast for optimal performance; Suitable for M.2 SSDs, with high bandwidth, it can achieve the highest transmission while simultaneously meeting the requirements of 4 SSDs Losing speed. Suitable for host centric point-to-point communication mode, it can be configured for various graphics applications.
