1. Compatible with HD-TVI, HD-AHD signals.
2. Twisted pair video Baluns, for sending video signals up to 2000ft / 600m.
3. Allows video signals to be transmitted over UTP (CAT5) Cable.
4. Allows BNC male connector to be connected with camera or DVR.
5. Built-in surge and transient protection. Super interference rejection.

Spec:
Description:
This Video Transceiver is a passive (non-amplified) device that allows the transmission of real-time monochrome or color video over Unshielded Twisted Pair (UTP) telephone wire. Video signals are routed via UTP (Cat5) cable.
Features:
Compatible with HD-TVI, HD-AHD signals.
Twisted pair video Baluns, for sending video signals up to 2000ft / 600m.
Allows video signals to be transmitted over UTP (CAT5) Cable.
Allows BNC male connector to be connected with camera or DVR.
Built-in surge and transient protection. Super interference rejection.
Compact size and easy installation.
Specifications:
Transmission distance: 600M for 720P ; 300m for 960H / 1080P ; 200m for 720P / 1080P HDTVI
UTP cable: CAT5 cable
Video format: AHD / CVI / TVI
Resolution: 720p / 960H / 1080p
Working frequency: DC to 6MHz.
Common Mode / Differential Mode Rejection: 15khz to 5MHz 60 dB typ.
Attenuation: 1.5db typ
Male BNC impedance: 75Ω
Video Input: 2kv (common mode), 10 / 700us iec6100 -4 / 1995 (GB / T
Video output: 2kv (common mode), 10 / 700us iec6100 -4 / 1995 (GB / T
Dimension: 4.1 * 2.2 * 1.5cm with 12cm cable
Color: Black
Material: ABS
Package weight: 47g
Quantity: 2 pcs (1 pair)
Package Included:
2Pcs x BNC Passive Video Balun
