Linear Motion Guide Actuators
For example:
if stroke length is 30mm, then L=140mm;
if stroke length is 550mm, then L=710mm;
if stroke length is 900mm, then L=1010mm.
Comparsion Of Linear Actuators
Series
IP40X
IP42
IP60
IP800
IP1200
IP3000
Input Voltage
DC 24V
DC 9-32V
DC 12V
DC 12V/24V
DC 12V/24V
DC 12V/24V
Max Speed
25mm/s
80mm/s
30mm/s
52mm/s
88mm/s
88mm/s
Max Thurst
1000N
200N
150N
800N
2500N
3000N
Stroke Length
50~1000mm,
or
50~1000mm,
or
30~150mm,
or
30~1000mm,
or
30~1000mm,
orcustomized
30~1000mm,
or
Limit Switch
Yes
Yes
Yes
Yes
Yes
Yes
Rated Power
of DC 24V
60W
36W
N 30W
60W
60W
Rated Power of
DC 12V
N 36W
30W
30W
30W
30W
Rated Current
2A
1.5A
0.25A
3A/4A
3A/4A
3A/4A
Purchase
To buy
To buy
To buy
To buy
To buy
To buy
==========
Torque : Max 800N 80KG 176lbs
Model Number : IP800-CG
Continuous Current(A) : 3A/4A
Construction : Magnet
Type : Gear Motor
Protect Feature : Drip-proof
Commutation :
Efficiency : IE 2
Output Voltage : 30W
Color : Gray
Input Voltage : DC 12V/24V
Limit Switch : Built-in
Noise : less then 48dB
IP Level : IP54
linear actuator 12v : Linear actuators
