Automotive Oscilloscope Testing Kit – Includes one HT30A automotive test lead, two HT201 20:1 attenuators and one HT307 acupuncture probe set. Designed to provide the connections, signal attenuation and fine probing accessories required for automotive electrical signal testing with compatible Hantek oscilloscopes
3-Meter Fully Shielded Test Lead – The HT30A features a male BNC connector and two color-coded 4mm connectors. Its approximately 3-meter length allows the oscilloscope to remain on a workbench while connected to the vehicle being tested or repaired. The fully shielded construction helps reduce external noise and signal interference
Two HT201 20:1 Attenuators – Each HT201 features a 20:1 attenuation ratio, 10MHz bandwidth and 1.053MΩ input resistance. Designed to assist compatible oscilloscopes in measuring automotive fuel injector and primary ignition waveforms
Multipurpose Fine-Tip Probes – The HT307 probes can be used for connector back probing, wire insulation piercing and pin-tip probing on small circuit boards. Their fine, sharp tips can slide past connector seals to access small and delicate terminals. Each probe features a female banana socket for connection to compatible test leads and measuring instruments
Repairable and Replaceable Probe Design – If an HT307 probe pin becomes bent, worn or damaged, the retaining screw can be loosened and the pin replaced without replacing the entire probe. Important: The HT201 is intended only for fuel injector and primary ignition signal measurements. Do not use it for secondary ignition testing or any other high-voltage measurement
