Model: ZHKY98B
Material: Alloy steel
Output:1.0~2.0 mV/V
Accuracy: ±0.1; ±0.3; ±0.5%F.S
Parameters :
Material
Alloy steel
Rated capacity
0~100,200,300,500,1000,2000,3000,5000Nm
comprehensive precision
±0.1; ±0.3; ±0.5%F.S(Linearity + Hysteresis + Repeatability)
Sensitivity
1.0~2.0mV/V
Zero output
0~±1%F.S
Temp. effect on zero
±0.1%F.S/10
Temp. effect on sensitivity
±0.1%F.S/10
Operating temp.
-35~+80
Compensated temperature range
20~+60
Input resistance
700±10/350±10
Output resistance
700±5/350±5
Insulation resistance
2000 M/100VDC
Power supply
12VDC
==========
Material : Stainless steel
Series : reaction torque sensor
Features : static reaction torque sensor
Description : static torque sensor, ZHKY98A torque sensor
Model Number : ZHKY98A
Type : TORQUE SENSOR
Model : reaction torque sensor
Capacity : 0N.m - 100 N.m
Torque accuracy : 0.5%/ 0.25% / 0.1%
Output type : Torque
Operating temp. : -20~+65
