Specs & OEs — 24VDC coil (approx. 8.3 mA, 200 mW; ~2880 Ω), SPST-NO (1-Form-A) contacts rated 5A @ 250VAC / 30VDC; max switching voltage 250VAC/30VDC; fully sealed; slim body ~6.5(W)×17.5(L)×12.5(H) mm; operating −25°C to 70°C; UL/CSA/TÜV approvals. Compatible with G6D-1A-ASI-DC24; cross-reference for identification: Compatible with G6D-1A-ASI DC24, G6D-1A-ASI-AP DC24, G6D-1A-ASI-AP2 DC24, G6D-1A-ASI-NP-DC24 (verify pinout/coil before purchase)
Install & location — Through-hole PCB relay for control boards; 2.54 mm pin grid (see footprint); non-polarized coil; recommended to add a flyback diode across DC loads; typical soldered installation on controller/IO/driver boards. Compatible with P6D-04P socket (optional) when socket-mounting is desired; remove relay before soldering the socket. Not intended for blade-style car fuse boxes. Symptoms of a failed board relay this replaces can include no output drive, stuck ON/OFF, or chattering.
Application fit — Designed for programmable controller and temperature-controller outputs and general board-level switching. Compatible with North-American control panel use cases such as PLC I/O modules, HVAC/temperature control boards, appliance/industrial controllers, vending/automation, CNC/3D-printer controller outputs (confirm electrical ratings). This is a PCB component; vehicle year/make/model fitment does not apply.
Performance & durability — Compact yet capable of 5A switching; durability tested up to 300k operations at 2A (resistive). Ambient humidity 5–85%RH. Shock/temperature characteristics and safety approvals documented in the datasheet for engineering validation. Fully sealed package helps resist flux and contaminants during assembly and service.
Complementary & cross-sell — Compatible with P6D-04P relay socket for serviceable mounting; keep a spare relay on hand for mission-critical control boards. If your board requires a different coil, see “Compatible with G6D-1A-ASI-DC12 / DC5” variants (same series; always match coil voltage and footprint before use)
وصف
Coil: 24V DC (≈8.3 mA, ≈200 mW; ≈2880 Ω)
Contact Form: SPST-NO (1-Form-A); Rating: 5A @ 250VAC / 30VDC
Max Switching Voltage: 250VAC / 30VDC
Enclosure: Fully sealed; Mounting: Through-hole (PCB)
Size (approx.): 6.5(W) × 17.5(L) × 12.5(H) mm
Approvals: UL / CSA / TÜV (see datasheet for details)
Recommended Socket (optional): Compatible with P6D-04P
Typical Use: Compatible with controller/temperature-controller outputs, PLC I/O, and general board-level switching where a slim 24VDC coil relay is specified. This is a PCB component and is not a blade-style automotive relay.
Cross-Reference (search/ID aid): Compatible with G6D-1A-ASI-DC24; also G6D-1A-ASI DC24, G6D-1A-ASI-AP DC24, G6D-1A-ASI-AP2 DC24, G6D-1A-ASI-NP-DC24. Always verify coil voltage, footprint, and contact ratings on your board before purchase.
Note: Replacing a worn relay can restore correct board outputs (e.g., eliminating no-start, stuck ON/OFF, or chattering issues) when diagnostics point to a failed contactor on the PCB.
