Linear Sensors
Theory : Resistance Sensor
Material : Metal
Type : Magnetic Sensor
Output : Analog Sensor
Use : Pressure Sensor
Capacity : 10~2000KG
Type : Load Cell/Force Sensor
Zero Balance : ±1%F.S
Sensitivity : 0.5-2.0mV/V
Non-linearity : ±0.3%F.S
Hysteresis : ±0.5%F.S
Repeatability : ±0.5%F.S
Rated output : 10-1.5mV/V(10-100kg)
Creep In 30 Minutes : ±0.5%F.S
Temp Effect on Zero : ±0.05%F.S/ 10
Temp Effect on Output : ±0.05%F.S / 10
Operating Temp Range : -20 ~ 60
Input Impedance : 380±30 OR 500±5 OR 1000±30
Output Resistance : 350±5 or 500±5 or 1000±5
Insulation resistance : 5000M//100VDC
Recommended Excitation : 5~12V
Safe Overload : 120%
Material : stainless steel
Output : Analog Signal
