Linear Sensors
Theory : Resistance Sensor
Material : Metal
Type : Magnetic Sensor
Output : Analog Sensor
Use : Pressure Sensor
Capacity : 1~100KG
Type : Load Cell/Force Sensor
Rated output : 0.5-1.0mV/V(3-5kg),10-1.5mV/V(10-100kg)
Zero Balance : ±2%F.S
Non-linearity : 0.5%F.S
Hysteresis : ±0.1%F.S
Repeatability : ±0.1%F.S
Creep In 30 Minutes : 0.2%F.S
Operating temp. range : -20 ~ 80
Temp. effect on Output : 0.5% F.S. / 10
Temp. effect on Zero : 0.5% F.S. / 10
Impedance : 1000
Output Resistance : 350±5 or 500±5 or 1000±5
Insulation resistance : 2000M//100VDC
Recommended Excitation : 5~10V
Safe Overload : 120%
Ultimate Load Limit : 150%
Cable Size : 2*2m diameter
Material : stainless steel
Output : Analog Signal
