Audio Transformers
Primary impedance: 3.5K/2.5K three wire
Secondary impedance: 0-4 -8 three wire
Power: 15W
Primary inductance: approximately 16H measured at 100HZ
Primary resistance: 295
Secondary resistance: 1.3 (measured at the 8 end)
Primary current: 80mA
Secondary current: 1500mA
Leakage sensing: approximately 6mH measured at 1KHz
Distributed capacitance: approximately 6000p measured at 20KHz
Frequency response: 20Hz-24KHz -0.5DB, 30KHZ-1DB
Volume: 90X65X70mm
Transformer weight: 2.8KG/pair
