مميزات خاصة

1. This portable spectrometer is designed for accurate measurement of color temperature, illuminance, and photosynthetic photon flux density (PPFD)
2. The Handheld PPFD Spectrometer features a plastic shell with an IP53 rating, ensuring protection against dust and water splashes
3. Equipped with an open-type optical interface (11.8mm diameter cosine corrector)
4. The Handheld PPFD Spectrometer operates within a spectral application range of 340-1000 nm, measuring illuminance up to 300,000 lux and color temperature from 300 to 800,000 K
5. With a frame rate of 10 fps and an adjustable integral time between 0.1-2000 ms

وصف

Specifications:
Name: Portable Spectrometer
Shell material: plastic
Waterproof and dustproof: IP53
Optical interface: Open type, with a diameter of 11.8mm cosine corrector
Data interface: TTL4
Frame rate (fps): 10
Integral time (ms): 0.1-2000
User self calibration/automatic adjustment of integration time function: not available/adjustable
Spectral application range (nm): 340-1000
Spectral resolution (FWHM) (nm): 7 @ 404, 7 @ 661, 7 @ 801
Signal to noise ratio/total illumination accuracy/chromaticity coordinate accuracy/chromaticity coordinate repeatability: 200:1/4%/± 0.004/± 0.002
Output wavelength interval (nm)/spectral accuracy (repeatability) (nm)/amplitude linearity/digital dynamic range/illuminance measurement range (lux)/color temperature measurement range (K): ± 1/0.9900/20bit/2-300000/300-800000
Measurement parameters: color temperature, color coordinates, illuminance, photosynthetic photon flux density (PPFD)
