Pumps
LLS Plus V3 Peristaltic Pump Closed Loop Stepper Motor
AC110V-220V Variable Speed 180ml/min High Precision Pump
Power Supply: 110V-220V, Power: 50W Max., Weight: 2.2kg, Flow Rate: 180ml/min, High-precision closed-loop stepper motor, extended life, low noise (less than 59dB).
Tube size: BPT tube (inner diameter x outer diameter: 3.2mm x 6.4mm); easy and quick replacement of pump tube.
2.8 inch color display with 6 buttons display operating parameters for easy operation. (Two language modes, Chinese and English display.)
This smart peristaltic pump can be used when connected to mains and is equipped with a control pedal for switching on and off.
Several external control options are available, including digital input, analog voltage and current control. RS485 communication is included for convenient control of controls. It can be configured for time-delayed and quantitative operation according to customer needs.
This small liquid metering pump is suitable for filling and sub-conditioning in industrial, laboratories and scientific research institutes, constant volume for cosmetics and beverages, and calcium reactors in aquariums.
What's included?
Host
Power adapter
Foot switch
Can be used in
Laboratory: Liquid transfer
Industry: Semi-automatic fluid packaging
Medical: Semi-automatic reagent dispensing
==========
Speed : 350
Flow Rate : 180ml/min
High-concerned chemical : None
Application : Metering
Theory : Rotary Pump
Structure : Peristaltic Pump
Model Number : LLS Plus V3
Standard or Nonstandard : Standard
Power (W) : Electric
Voltage : AC 110~220V
Weight : 2.208KG
Maximum Power : 50W
Maximum Speed : 350 rpm
Speed regulation resolution : 0.1 rpm
Motor type : Stepper motor
Motor life : 6000 hours
Reference noise value : 59dB (the horizontal distance between the product and the noise meter is 0.5 meters)
Interface : Buttons, Foot Switch, External Analog (0-5V, 0-10V or 4-20mA), RS485 Communication
Number of rotors : 3 rotors
Tubing diameter : ID3.2mm x OD6.4mm
Accessory : Foot Switch(Standard Configuration)
