Circuit Breaker, Amps 125, Number of Poles 2, Circuit Breaker Type Standard, AC Voltage Rating 240VAC, DC Voltage Rating Not Rated, For Use With -, Series QD, Trip Type Thermal Magnetic, Terminal Connection Lug, Max. AIR Rating 25 kA, Phase Connection -, Mounting Free Standing, Height 6.47 In., Width 3.00 In., Depth 3.93 In., Min. Wire Size 4 AWG, Max. Wire Size 300 kcmil, Instantaneous Trip Fixed, High Amp Trip Setting 2400A, Low Amp Trip Setting 1200A, Frame Size 250A/QD
Specifications:
Standards: UL Listed, CSA Certified, CE Marked, IEC
Amps: 125
Phase Connection: -
Terminal Connection: Lug
Instantaneous Trip: Fixed
Mounting: Free Standing
Item: Circuit Breaker
Width: 3.00"
Circuit Breaker Type: Standard
Low Amp Trip Setting: 1200A
Min. Wire Size: 4 AWG
Height: 6.47"
Number of Poles: 2
DC Voltage Rating: Not Rated
High Amp Trip Setting: 2400A
Depth: 3.93"
AC Voltage Rating: 240VAC
Frame Size: 250A/QD
Phase: 1
For Use With: -
Series: QD
Max. AIR Rating: 25 kA
Max. Wire Size: 300 kcmil
Trip Type: Thermal Magnetic
