TRC Ø6 Mini Flexible Rogowski Coil Specifications

Basic Information
Product Type: Flexible Current Sensor
Application Scenarios: Energy consumption monitoring, high-frequency current monitoring, DC ripple measurement, etc., can be used with portable devices such as power analyzers
Protection Rating: IP67
Material
Coil Cable: Thermoplastic rubber for wires and cables, FUL 94 V-0 retardant
Connector: PC
Coil Color: Orange
Shielding: Coil 100%, Signal Cable 100%
Insulation Voltage: Coil 3000V, Signal Cable 1000V
Safety Rating: 1000V CATIII, 600V CATIV
Features: Good linearity, dynamic range 1A~500kA, strong overload capacity, resistance to interference from adjacent conductors, no open circuit high voltage hazard, zero power consumption, small positional error, flexible, lightweight and easy to install, large bandwidth, with lead seal

Electrical Performance Parameters
Table
Parameter Item Technical Specifications
Reference Current ≤500kA
Maximum Current 500kA
Weight 80-100g
Coil Resistance 50-300Ω
Turning Ratio (Calibrated) 50±0.2%mV/kA@50Hz
Turning Ratio (Uncalibrated) 60±5%/65±0.5%mV/kA@50Hz
Internal Resistance Temperature Drift Coefficient Uncalibrated: 200ppm/℃; Calibrated: 50ppm/℃
OA Output (Zero Drift) ≤1mV
Angle Difference ≤0.5°
Linearity ±0.2%
Bandwidth 1Hz-20kHz/50kHz (-3dB)
Operating Temperature -40℃~80℃
Storage Temperature -50℃~90℃
