[LARGE DETECTION RANGE]: Detects RF signals from -55dBm to 0dBm with output voltage proportional to the logarithm of input amplitude, enabling expanded dynamic range for precise RF power measurement in wireless communication and systems.
[HIGH-PERFORMANCE CHIP]: Built around the advanced AD8317 logarithmic amplifier chip, ensuring accurate RF signal power detection from 1MHz to 10GHz frequency range for consistent and reliable performance in various RF applications.
[COMPACT & EASY INSTALLATION]: Compact PCB design with 50 Ohm input/output impedance and simple wiring allows fast integration into existing setups, saving time and effort while providing durable long service life for continuous operation.
[VERSATILE APPLICATIONS]: Ideal for RF transmitter PA setpoint control, power monitoring in base stations, RSSI measurement in WLAN, WiMAX, , and environmental field strength detection for professional RF engineers and hobbyists alike.
[TRUSTED ACCURACY & RELIABILITY]: High linear dynamic range with -22mV/dBm input to output ratio and stable 3.3-5V DC power supply at 20mA ensures reliable, precise readings, providing confidence in measurement critical for RF signal testing and monitoring tasks.

وصف

Item Type: Logarithmic Detector Module
Material: PCB
Input Impedance: 50 Ohms
Output Impedance: 50 Ohms (Video Impedance)
Operating Frequency Freq: 1MHz - 10GHz
Output Voltage Range: 1.6 -0.4V (corresponds to -55-0 dBm)
Input to Output Ratio: -22mV/dBm
Input Dynamic Range: -60-5 dBm (High Linear Dynamic Range: -55-0 dBm)
Product Supply Voltage: 3.3-5V DC at 20mA
Applications:
RF transmitter PA setpoint control and level monitoring
Power monitoring base stations in radio line transmitters
RSSI measurement in WLAN, WiMAX and

Package List：
1 x Logarithmic Detector Module
