Pressure Gauges
Measure range-normal:
0.1Mpa,0.16Mpa,0.25Mpa,0.4Mpa,0.6Mpa,1Mpa,1.6Mpa,2.5Mpa,4Mpa,6Mpa,
measure range-high pressure:10Mpa,16Mpa,25Mpa,40Mpa
Connection thread:M14X1.5
If you need others thread. Please take a message to us. We will check for you
Technical parameters
Name
Model
Nominal diameter(mm)
Accuracy grade
Measuring range(Mpa)
Connection thread
Contactor power
(VA)
Max. operating voltage
(V)
Control mode
electric connecting pressure gauge
YX-60
60
2.5
0~0.1~60
M14×1.5
10
DC220VorAC380V
top and bottom limitation
YX-100
100
1.6
0~0.1~100
-0.1~0~2.4
M20×1.5
10
DC220V or AC380V
top and bottom limitation
YX-150
150
1.6
0~0.1~100
-0.1~0~2.4
M20×1.5
10
DC220Vor AC380V
top and bottom limitation
Magnetic help
electric connecting pressure gauge
YXC-100
100
1.6
0~0.1~100
-0.1~0~2.4
M20×1.5
30
DC220VorAC380V
top and bottom limitation
YXC-150
150
1.6
0~0.1~100
-0.1~0~2.4
M20×1.5
30
DC220VorAC380V
top and bottom limitation
oxygen electric connecting pressure gauge
YXCO-100
100
1.6
0~0.1~60
M20×1.5
10
DC220VorAC380V
top and bottom limitation
YXCO-150
150
1.6
0~0.1~60
M20×1.5
10
DC220VorAC380V
top and bottom limitation
Ammonia use electric connecting pressure gauge
YXCA-100
100
1.6
0~0.1~60
M20×1.5
10
DC220VorAC380V
top and bottom limitation
YCXA-150
150
1.6
0~0.1~60
M20×1.5
10
DC220VorAC380V
top and bottom limitation
rating of temperature electric connecting pressure gauge
YXCW-100
100
1.6
0~0.1~60
M20×1.5
10
DC220VorAC380V
top and bottom limitation
YXCW-150
150
1.6
0~0.1~60
M20×1.5
10
DC220VorAC380V
top and bottom limitation
shock-proof
electric connecting pressure gauge
YXC-100N
100
1.6
0~0.1~60
M20×1.5
30
DC220VorAC380V
Model Number : YXC60ZT
Max Measuring Range : 200 PSI & Above
Display Type : analog
Dial Diameter : 2 - 3.9 Inches
DIal size: : 60MM
connection: : brass and bottom
Thread : M14*1.5 or 1/4"Better Sports Performance
movements: : Brass
is_customized : Yes
