Details
Long Connecting Cable: The 3.28ft cable allows you to have enough disposable length for easier use, and can also further protect your safety.

Round Corners: Compared with traditional square corners, an arc design without a burr can better care for your skin.

Multiple Power Cords: Different colors of power cords allow you to easily connect them without confusion.

How to Install
1.Please remove the holster before installation.
2.Fix the reducer on the gear motor with four M5 screws(not included).
3.Install the keyway at the keyway opening.
4.Plug the speed controller and gear motor together (main wire to main wire).
5.Unscrew the two AC screws(not included) on the back of the speed controller.
6.Connect single-phase power to both AC ports (without distinguishing between zero and fire wires) and tighten the screws.
7.Turn the speed control knob to adjust the motor speed.
8.Install the stand on the motor.

Specification
Color: Gray
Name: 4GN-60K Gear Head
Model: M425-402
Material: Cast Aluminum
Processes: Plastic Spraying, Integration, Heat Treatment Process
Type: AC Gear Motor, Induction Motor
Shape: Square, Round
Feature: Portable
Power Phrase: Single-phrase
Motor: Pure Copper Motor
Noise: About 50db
Built-in Fan: ＞60W
Torque: About 8N.m
Voltage: AC 110V
Power: 25W
Capacitance: 2UF
Adjustable Speed: 0-100%
Assembly Required: Yes
Suitable Screw: M5 (Not Included)
Speed: 50Hz 90-1350r/min, 60Hz 90-1650r/min
Reduction Ratio: 1:60 (60K)
Temperature: -10-60℃/14-140℉
Connecting Line Length: About 1m/3.28ft
Shaft Diameter: 10mm/0.39inch
Shaft Height: 27mm/1.06inch
Speed Controller Size: 9*6*10cm/3.5*2.4*3.9inch
Motor Size: 6.7*8*9.7cm/2.6*3.2*3.8inch
Reducer Size: 6.7*8*4.6cm/2.6*3.2*1.8inch
Stand Size: 16*7.5*12.5cm/6.3*3*4.9inch
Stand Top Length: 10.4cm/4.1inch
Package Size: 24*24*12.5cm/9.45*9.45*4.92inch
Net Weight: 2.5kg/5.51lbs
Gross Weight: 3kg/6.61lbs

Package Included
1* Gear Motor
1* Speed Controller
1* English Manual
1* Stand
