What's included in package:
1pcsUSR-N510
1pcs power adaptor
USR-N510 is a serial device server,whose function is to realize bidirectional transparent transmission between RS232/RS485/RS422 and Ethernet. Product DescriptionBrand protection, high-level protection in serial port, Ethernet port and power supply, suitable for more harsh industrial environment. Cortex-M4 kernel, industrial grade working temperature, and IP protocol stack, more stable. Ethernet 10/100Mbps, support Auto-MDI/MDIX Support Server, Client, UDP, UDP Server, Httpd Client work modes A port can correspond 2 Sockets Support network printing Support ModBus upport virtual serial port and provide corresponding software USR-VCOM Serial baud rate from 600bps~230.4K bps, support 5 check methods: None, Odd, Even, Mark, Space Support static IP, DHCP, can inquire network device via UDP broadcast protocol Offer serial and network setting protocol, key codes instruction, user can integrate parameter setting function into their application software Provide PC /IP socket programming examples such as VB, Andriod, etc. Built-in webpage, also can customize webpage for users. Reload button, one key to restore default . RJ45 with Link/Data indicator light, built-in isolation transformer and 2KV electromagnetic isolation. The global MAC address bought from IEEE (begin with D8-B0-4C), user can define MAC address. Support upgrade firmware via network Support ARP of server domain name Support changing of network port(default 80) Support keep alive, rapidly detect dead links. Support account and password, can be used to webpage login and network . Serial work as RS232/RS485/RS422, DB9 female, provide RS485/RS422 converter Support DC adapter and 5.08-2 terminal power supply, wide range 5~36V Support UDP broadcast function
Certification : CE
