*Using TYPE C and Mini USB interface, applied to communication and automatic control
*Capable of change display orientation for easy operation with left, right hand
*Upper and lower limit alarm can be set
*Capable of printing single or multiple records
*Display full information, intuitive and graphical displays all parameters
*Built in lithium- rechargeable battery and control circuit, high capacity, no memory effect
*The tester can graphically display the remaining battery power
*Continuous working time 20 hours
*Large capacity data storage, can store 100 item of data and measured profile
*Real-time clock setting and display for easy data recording and storage
*With automatic sleep, automatic shutdown power-saving features
*Reliable circuit and software design of prevent the motor stuck
*language: Chinese/English
*All parameters can be printed or print any of the parameters which set by the user
*The glass calibration sample is with high precision, not easy to be scratchedand long
The displacement differential inductance
Stylus
Traversing speed
lr=0.25, Vt=0.135mm/s
lr=0.8, Vt=0. 5mm/s
lr=2. 5, Vt=1mm/s
Return Vt=1mm/s
Accuracy
±(5nm+0.1A) A: Ra of calibration test block
Repeatability
No more than 3%
Residual profile
No more than 0.010m
Power supply
Built-in 3.7VLithium battery,Charger:DC5V,800mA/3hour
Outline dimension L×W×H
142×55×40mm
Weight
About 350g
working Environment
Temperature:- 20 ~ 40
Store and Transportation
Temperature:- 40 ~ 60
Humidity:
