Output waveforms: sine wave, square wave, triangle wave, forward sawtooth wave, reverse sawtooth wave, ECG
wave, exponential rise, exponential fall, Lorentz pulse, Gauss pulse, Sinc pulse, half-wave, fll-wave, Schumann wave, noise
wave, and so on 15 kinds of waveforms.

Power supply: DC4-9V, DC5V is recommended when using adapter, 3.7V lithium battery is recommended when using
battery power.

Current: 180MA at voltage 5V

Frequency range: sine wave 0.01Hz- 500.00kHz (with further increase in frequency, the output amplitude will
decrease), other waveforms 0.01Hz-100.00kHz (but does not limit the upper limit of the adjustable frequency, if the
distortion and jitter requirements are not high, the use of frequency can be further increased).

Resolution: 0.01Hz.

Output amplitude: Maximum t10V (P-P).

output impedance: 50 ohms.

DC offset: maximum10V, with shutdown function.

All setup parameters can be saved.

there are filters can be turned on and off, can be well adapted to sinusoidal and pulse waveform output.
