مميزات خاصة

Product Advantage; The row of wires has excellent electrical properties, dielectric properties, heat resistance. It can be moved, bent and twisted without damaging the wires and can comply with different shapes and special package sizes. The only limitation is the volume and space.
Easily inserted directly into PCBs。
Durability; because it can withstand millions of dynamic bends, the cable is well suited for use in inline systems where continuous or periodic movement is part of the product's functionality.
Flat ribbon cables are securely attached to the pins for quick circuit experimentation. It can be reused without damage to the terminals.
FC row header pins are nickel-plated and gold-plated then tin-plated material oxidation-resistant, conductive, and have good transmission performance.
Ribbon cable saves space and time in circuit interconnecting components. Using standard wire connectors, jacks and pins, conductor ribbon cables can be easily separated for clean terminations.
Widely used for internal wiring of computers, instruments, machines, appliances, LED displays, automobiles, color TVs, air conditioners, DVDs and other machines.

وصف

Connector Type: 14 Pin Connector Gray Flat Ribbon Cable (Female to Female) Connector Type; Female IDC Connector Number of Pins: 14PIN Width; 17.78 mm/0.7 inch Length; 30 cm/11.8 inch Connector Pitch: 2.54mm Cable Pitch: 1.27mm Wire Leads: 28 AWG Temperature rating; 105C Rated Voltage; 300V Withstanding Voltage; 2500V Insulation Resistance; 100-M-km Characteristic Impedance; 105 Flame Retardant Grade; yw-1 On-time; 4.2ns/m Capacitance; 44pF/m Attention; This product is 1.27mm row of wires supporting 2.54mm crimp header. 2.54mm pitch:The representation means the distance between two holes is 2.54mm. 1.27mm gray row of wires: refers to the center distance between the two spellings is 1.27mm. When purchasing, please choose the corresponding crimp head/row wire according to your needs. Please check whether it is the product you need before payment. Please allow 0-2 cm error due to manual measurement (1 inch = 2.54 cm). The picture may not reflect the actual color of the product, please refer to the actual product. Please make sure you don't mind before bidding. Thanks! Package Contents; 2 pcs gray flat ribbon cable (female to female). Only the above package content is included, other products are not included.
