Ohmmeters
1. Name: Ammeter 44C2-A DC pointer ammeter
2. Dimensions: 100*80mm
3. Aperture size: 70*60mm

Installation position: The instrument is suitable for vertical installation, and a tilt of ±5 degrees is allowed; unless otherwise specified.
Pointer deflection angle: from left to right
Storage temperature: -40℃-+70℃
Damping time: ≤4S
Working environment: temperature: -20~+40℃, relative humidity less than 85%, no dust or corrosive gas.
Dielectric strength: Withstand voltage test: Can withstand 50HZ sine wave AC 2kV voltage for 1 minute.
Insulation resistance: greater than 20MΩ/DC500
Batteries Included: No
Size: 80MMX100MM
Working temperature: -20~40 degrees
Supply voltage: DC
Accuracy grade: 1.5
: 44C2
