Specifications:
Material: Aluminum alloy
Full Power Bandwidth Range (Sine): DC~100KHz
Max. Output Amplitude(Dual Channel Output Mode): 50Vpp(±25V), no load
Max. Output Amplitude(Dual Channel Differential Output Mode): 100Vpp(±50V), no load
Amplitude Range of Input Signal:
0-25Vpp (2 times gain)
0-5Vpp (10 times gain)
Max. Output Current: 1A
Max. Output Power:
both channels are output simultaneously, and each channel has a maximum output power of 30W
use only one channel output, the maximum output power can reach 40W

Heat Dissipation Method: Natural heat dissipation of shell
Voltage Gain: 2X and 10X, 2 gears optional
Gain Adjustment Method: Toggle switch adjustment
Input Impedance: ≥10KΩ
Output Impedance: ＜2Ω
Slew Rate: ≥10V/us
Safe Use Load Value: ≥4Ω
Power: DC12V power Input
Item Size: 150 * 97 * 52mm / 5.91 * 3.82 * 2.05in
Item Weight: 823g / 29.03oz
Package Weight: 1100g / 38.80oz
Package Size: 20 * 17 * 8cm / 7.87 * 6.69 * 3.15in
