Transformers
Module Properties:Non-isolated module
InputVoltage: DC 12V24V
InputVoltage Range: DC (8V-40V)
Output Voltage: DC 5V
Output Current:1-10A
Output Power:5W-50W
Conversion Efficiency: >93%
Cable Length: 13-14cm
Ripple (Full load test): 40mV
No-loadcurrent: 25mA
Working Temperature: -40~80
( If ambient temperature exceeds 40°C, lower power use, or to enhance heat dissipation)
Waterproof Rating: IP67
Protection: Over-current/Over-voltage/Over-heat/Short-circuit Anti-shock , Anti-dust protection
Product size and weight : ABS Plastic M(1-5A),46*32*18MM,50g/pc
==========
High-concerned chemical : None
Output Current : 1-10A
Output Frequency : 43hz
Model Number : XW-1224-5
Output Power : 51 - 100W
Type : DC/DC Converters
Weight : 53g
Size : 46*32*18MM
Output Type : SINGLE
Origin : Mainland China
Certification : CE,RoHS
Input voltage : DC 12V 24V
Input voltage Range : DC 8-40V
Output Voltage : DC 5V
Conversion Efficiency : >93%
Working Temperature : -30°C to +80°C
Shell : Plastic
Waterproof : IP67
