Temperature
Source: LED Red
Response time: 50us
Operation light: Red LED, dual digital display:
Dual 7-digit display, threshold (4-digit green light
The diode indicator lights up and displays the current value (4-digit red
LED indicator light).
Current value range: 0-9999

Duration: 1ms to 9999ms
Control output: NPN/PNP open collector 24V, maximum 100mA (main
Components) Maximum 20mA (Residual voltage: 1V. When
Extension component connection. Models with sensor
Analog output, analog voltage 0-5V, detection accuracy
1/1000 to 24 VDC ±10%, floating rate (): maximum 10% 2 levels
Working environment brightness:: Maximum:
20,000 lux, Daylight: Maximum: 30,000 lux
Power consumption: Standard mode: MAX 300 MAX
Voltage: 24V
Seismic: 10 to 55 Hz, double amplitude: 1.5 mm, x, y, z axes
2 hours
Ambient temperature: -10℃～+55℃, no freezing

Theory: Optical Sensors

Type: Photoelectric sensor
Output: switch sensor

Application: Position sensor
