Pneumatic Motors
Technical Parameters:
Rated power: 20W Maximum 30W
Stroke: 50mm/100mm
Permanent magnet DC motor drive;
Voltage: 12V,24V
Size:
L= Minimum installation distance
S= Effective stroke
Size introduction:
Stroke Length: means the movement length of linear actuator.
Retracted Length: means the length when linear actuator 100% fully closed.
Extended Length: means the length when linear actuator 100% fully open.
Stroke length introduction:
50mm Stroke, Retracted Length=155mm, Extended Length=205mm
100mm Stroke, Retracted Length=205mm, Extended Length=305mm
Torque : 100/300/500/700/1000/1200/1500N
Usage : BOAT
Model Number : Stroke 50mm/100mm/
Continuous Current(A) : 1~2A
Construction : Permanent Magnet
Type : Gear Motor
Commutation : Brush
Efficiency : IE 2
Output Power : 12~35W
Speed(RPM) : 4/6/10/15/20/35/60/90mm/s
Voltage(V) : 12VDC/24VDC/36VDC/48VDC
