The universal joint is made of premium metal material, which is durable and has a long service life.
This joint or coupling connects rigid rods whose axes are inclined to each other.
Coupling Universal Joint Are Used In Servo Motor Systems, 3D Printer, Cnc Machine, Diy Encoder, Spindle Transmissions, Stepping Motors, Lifting Platforms, Machine Tool Transmissions, Stepping Motors, Encoders, Screw Drives, Machine Platforms Or Gearboxes, Etc. The Purpose Is To Firmly Connect The Driving Shaft And The Driven Shaft To Rotate Together And Transmit Motion And Torque.
The shaft joint is commonly used for shafts that transmit rotary motion.
This universal joint is widely used for connecting model cars, model ships, robots, etc.

وصف

Metal joint suited to use direct axis motor, suitable for model cars, model ships, robots, and other metal adapter to use.
Package Included:
Universal Joint x 1
Screw x 2
Spanner x 1
"4mm-6mm" means "one hole diameter of the coupler is 4mm ,the other is 6mm"
2mm-2mm, 2mm-2.3mm, 2.3mm-2.3mm
Universal Joint Outside Diameter: 8mm
Universal Joint Length: 18mm
Side Screw Fixing Hole: M3
2mm-3mm, 2mm-4mm, 2.3mm-3mm, 2.3mm-4mm, 3mm-3mm, 3mm-3.17mm, 3mm-4mm, 3.17mm-3.17mm, 3.17mm-4mm, 4mm-4mm
Universal Joint Outside Diameter: 9mm
Universal Joint Length: 23mm
Side Screw Fixing Hole: M3
3mm-5mm, 3.17mm-5mm, 4mm-5mm, 4mm-6mm, 5mm-5mm, 5mm-6mm, 6mm-6mm
Universal Joint Outside Diameter: 11mm
Universal Joint Length: 23mm
Side Screw Fixing Hole: M4
5mm-8mm, 6mm-8mm, 6.35mm-8mm, 8mm-8mm
Universal Joint Outside Diameter: 14mm
Universal Joint Length: 35mm
Side Screw Fixing Hole: M4
Fixed Clamp Spring Design
8mm-10mm, 10mm-10mm
Universal Joint Outside Diameter: 16mm
Universal Joint Length: 35mm
Side Screw Fixing Hole: M4
Notice:
Due to different monitors, there may be some color difference, which is normal.
