Laminated Pull-type Continuous duty cycle rated at 25°CConstructed of durable laminated steel with corrosion-resistant frame and plunger. Solenoids have polyester or nylon bobbins, encapsulated or taped coils, steel plunger springs, and brass plunger guides. Class A coil insulation with solder lug coil terminals.SolenoidsRoHS Compliant.

Item: Solenoid
Solenoid Type: Laminated
Stroke Range: 1/8" to 1-1/4"
Pull Force Range: 192.0 to 256.0 oz.
Width: 2-3/8"
Depth: 2-15/16"
Length: 3"
Coil Volts: 240VAC
Seated Amps: 0.33
Seated Watts: 23.5
Coil Resistance: 26.0 ohm
Terminals: Solder Lug Coil
Amps @ Max. Stroke: 6.50
Duty Cycle: Continuous
Mounting Holes: 2 x 1-7/8"
Gravity Value: 12.64 oz.
Pull @ 1/2 In. Stroke: 1.0 oz.
Pull @ 3/8 In. Stroke: 2.0 oz.
Pull @ 1/4 In. Stroke: 4.0 oz.
Pull @ 1/8 In. Stroke: 10.0 oz.
