Note Different product models have different appearance size and weight parameters
Reduction ratio: 50
Rated Tq when inputting 2000r/min: 99 Nm (10 kgfm)
Allowable peak Tq at start and stop: 281Nm (29kgfm)
Maximum allowable average load Tq: 140 Nm (14kgfm)
Instantaneous maximum Tq allowed: 497 Nm (51kgfm)
Maximum allowable output speed: 4800 r/min
Allowable average input speed: 3500 r/min
Backlash: 14 Aresec
Reduction ratio: 80
Rated Tq when inputting 2000r/min: 153 Nm (16kgfm)
Allowable peak Tq at start and stop: 395Nm (40kgfm)
Maximum allowable average load Tq: 217 Nm (22kgfm)
Instantaneous maximum Tq allowed: 738 Nm (75kgfm)
Maximum allowable output speed: 4800 r/min
Allowable average input speed: 3500 r/min
Backlash: 9 Aresec
Reduction ratio: 100
Rated Tq when inputting 2000r/min: 178 Nm (18kgfm)
Allowable peak Tq at start and stop: 433Nm (44kgfm)
Maximum allowable average load Tq: 281 Nm (29kgfm)
Instantaneous maximum Tq allowed: 841 Nm (86kgfm)
Maximum allowable output speed: 4800 r/min
Allowable average input speed: 3500 r/min
Backlash: 7 Aresec
Reduction ratio: 120
Rated Tq when inputting 2000r/min: 178 Nm (18kgfm)
Allowable peak Tq at start and stop: 459Nm (47kgfm)
Maximum allowable average load Tq: 281 Nm (29kgfm)
Instantaneous allowable maximum Tq: 892 Nm (91kgfm)
Maximum allowable output speed: 4800 r/min
Allowable average input speed: 3500 r/min
Backlash: 6 Aresec
Reduction ratio: 160 (need to be )
Rated Tq when inputting 2000r/min: 178 Nm (18kgfm))
Allowable peak Tq at start and stop: 484Nm (49kgfm)
Maximum allowable average load Tq: 281 Nm (29kgfm)
Instantaneous allowable maximum Tq: 892 Nm (91kgfm)
Maximum allowable output speed: 4800 r/min
Allowable average input speed: 3500 r/min
Backlash: 5 Aresec
