مميزات خاصة

The signal generator supports multiple adjustable modes including PWM mode, pulse mode, signal source mode, sine mode.
Hand-held signal generator is easy to carry, easy to operate and practical.
Built-in 1000mAH, 3.7V rechargeable lithium battery, it can work continuously for 8 hours after the battery is fully charged.
The voltage, frequency and duty cycle are all adjustable at PWM mode, with a high accuracy of 0.1%.
Frequency of sine and triangular can be adjusted in a wide range.

وصف

Power Supply Voltage: USB 5V

Product Function: PWM mode, pulse mode, signal source mode, sine mode

PWM Mode: Voltage, frequency, duty cycle are adjustable, frequency accuracy of 0.1%; voltage range: 1-24v, frequency range: 1-150khz, duty cycle range: 0-100%

Pulse Mode: Initial delay time t0: 0-60s, high level time t1: 0-60s, low level time t2: 0-60s, pulse number p-n: 1-99999999, resolution: 0.001 s

Signal Source Mode: Voltage source 2-10V adjustable, current source 4-20mA adjustable

Sine Mode: 1-999999HZ adjustable (triangular adjustable range is the same)

Signal Load Capacity: Output current maximum 20mA (Note: This product is output is a signal source, can not directly drive high-power load)

Environment Temperature: -10 ~ +70℃

Size(LxWxH): 92 x 70 x 28mm / 3.6 x 2.8 x 1.1in

Built-in Battery: 3.7V lithium battery, 1000mAH
