Measurement Parameters (μm): Ra, Rz, Rq, Rt
Measuring Range (μm): Ra, Rq: 0.05 to 10.0; Rz, Rt: 0.1 to 50
Sampling Length (mm): 0.25, 0.80, 2.50
Evaluation Length (mm): 1.25, 4.0, 5.0
Stroke Length (mm): 6
Indication Accuracy: 0.01
Indication Error: ±(7-10)%
Sensor Stylus Tip Radius and Angle: Tip Radius: 10 μm ± 1 μm
Sensor Stylus Static Force and Change Rate: Stylus Static Force: ≤ 0.016 N; Force Change Rate: ≤ 800 N/m
Sensor Tip Pressure: ≤ 0.5 N
Dimensions: 106 mm × 70 mm × 24 mm
Weight: 200g
