Note Different product models have different appearance size and weight parameters
Reduction ratio: 50
Rated Tq when inputting 2000r/min: 11 Nm
Allowable peak Tq at start and stop: 23Nm
Maximum permissible average load Tq: 18 Nm
Maximum Tq allowed instantly: 48 Nm
Maximum allowable output speed: 7300 r/min
Allowable average input speed: 3500 r/min
Backlash: 20 Aresec
Reduction ratio: 80
Rated Tq when inputting 2000r/min: 15 Nm
Allowable peak Tq at start and stop: 29Nm
Maximum permissible average load Tq: 19 Nm
Instantaneous maximum Tq allowed: 61 Nm
Maximum allowable output speed: 7300 r/min
Allowable average input speed: 3500 r/min
Backlash: 20 Aresec
Reduction ratio: 100
Rated Tq when inputting 2000r/min: 16 Nm
Allowable peak Tq at start and stop: 371Nm
Maximum permissible average load Tq: 27 Nm
Maximum Tq allowed instantly: 71 Nm
Maximum allowable output speed: 7300 r/min
Allowable average input speed: 3500 r/min
Backlash: 20 Aresec
