Introduction
FR2000C+ ground resistance tester is microprocessor controlled, can accurately detects ground resistance and leakage current.
It stores 500 groups of data, online monitoring data through monitoring software,
USB data uploaded to PC ,and has unique features such as value retention and intelligent alarm prompting.
FR2000C+ ground resistance tester consists of host computer, monitoring software, test line, USB cable, and grounding pin.
It has the functions of reading, viewing, saving, reporting and printing of historical data.

Specification
Model: FR2000C+
Resistance Range: 0.01Ω-1200Ω; Resolution: 0.001Ω; Accuracy: ±1%±0.01Ω
Current Range: 0.00mA-20.0A; Resolution:0.01mA; Accuracy: ±2%±1mA
Measurement Method: Mutual induction
Clamp Diameter: 65mmx32mm
Clock: Have
Ω+A Synchronized display: Ω+A same screen display
LCD Dimension: 46mm×29mm
Sampling Speed: 2 times/second
Data Storage: 300 Groups, the symbol “MEM” gives indication, “FULL” mark will flash to indicate the memory has been full
Data Review: "MR" symbol indication when reviewing data
Overflow Display: Exceed measurement range overflow function: “OL ” symbol display
Interference Test: Automatic identify interference signal, "NOISE" symbol indication when the interference current is large
Alarm Function: Alarm value exceeds the setting value
Battery Voltage: Reminding timely charging when battery voltage is low
Automatic shut-down: "APO" instruction, automatic shutdown after 5 minutes boot
Power Consumption: 50MA Max
Insulation Resistance: 20Ω or more (500V between circuit and outside)
Pressure Resistance: AC 3700V/rms
