Motor Speed Controllers
Working voltage
12, 24, or 32 VDC
Normal operating current
2A at 12VDC
Continuous rated maximum current
6A at 12V DC
Performance
Available Torque
Max 1.0 ib-ft (1.4Nm)
Maximum operating shaft Augular travel ACB/ACE
20±1 degree CW/CCW
Maximum operating shaft Augular travel ADB/ADC
25+ 1 degree CW/CCW
Environmental
Temperature Range
-65 to + 200F(-54 to +95 C)
Relative Humidity
All Surface Finishes
Fungus Proof and Corrosion Resitant
Reliability
Vibration
up to 20 G 100 50-500 Hz.
