Take Control with a Durable, Easy-to-Install Toggle Switch
Upgrade your vehicle's functionality or complete your custom electronics project with confidence using our Heavy-Duty SPST Toggle Switch. Built to withstand the rigors of automotive and marine environments, this switch offers a perfect blend of robust construction, straightforward operation, and installation-friendly design. Whether you're a seasoned mechanic or a DIY enthusiast, this switch delivers reliable performance where it counts.
Product Features & Specifications:
Solid Construction: The switch features a durable metal shell for longevity and a black plastic rocker arm that provides a comfortable and positive tactile feel with each operation.
Clear Electrical Ratings: Safely handle your electrical loads with a rating of 6A at 125V AC or 3A at 250V AC. This makes it suitable for a wide array of low to medium-power 12V/24V DC applications commonly found in vehicles and boats.
Installation-Ready Design:
Pre-Soldered Leads: Two insulated wires (Black and Red, approximately 5.2" / 131mm long) are already attached, saving you the step of soldering and ensuring a solid connection.
Standard Mounting: Fits a 12mm (0.47-inch) round mounting hole. The kit includes a securing nut and a lock washer for a secure, vibration-resistant installation.
Compact Dimensions:
Panel Cutout Required: 25mm x 15mm (0.98" x 0.6")
Overall Height (behind panel): ~37mm (1.5")
Rocker Arm Length: 11.5mm (0.45")
How to Install :
Drill or prepare a 12mm diameter hole in your panel.
Insert the switch body through the hole from the front.
From the back, thread on the provided lock washer and nut, and tighten securely.
Connect the two pre-wired leads to your circuit (typically one to power source and one to the device you wish to control). Use appropriate connectors (e.g., butt connectors) for a secure fit.
Common Applications:
Automotive: Fog light switches, off-road light bars, interior LED light control, auxiliary fan switches, air compressor control.
Marine: Bilge pump manual override, navigation light control, cabin light switches, accessory power control on boats.
General Use: DIY electronics projects, custom computer cases, industrial control boxes, hobbyist robotics, and model making.
