Resistor Units
Model TYPE
RTP20
RTP35
RTP50
Power Rating (25°C)
20W
35W
50W
Thermal Resistance
6.5°C/W
6.5°C/W
6.5°C/W
Resistance Range
0.11M
0.11M
0.11M
Tolerance
±0.5%;±1%;±5%
±0.5%;±1%;±5%
±0.5%;±1%;±5%
TCR (Temperature Coefficient)
±50ppm/°C;±100ppm/°C;±250ppm/°C
±50ppm/°C;±100ppm/°C;±250ppm/°C
±50ppm/°C;±100ppm/°C;±250ppm/°C
Max Working Voltage
350V
350V
350V
Operating Temperature Range
-55°C to +125°C
-55°C to +125°C
-55°C to +125°C
Climatic Category
55/125/56
55/125/56
55/125/56
Characteristics
Test Item
Specifications
Test Method
Short-time Overload
R ±(0.25%R + 0.05)
4.13
Rapid Temperature Change
R ±(0.25%R + 0.05)
4.19
Life
R ±(1%R + 0.05)
4.25.2
Damp Heat, Steady State
R ±(1%R + 0.05)
4.24
Climatic Sequence
R ±(1%R + 0.05)
4.23
LXP Series 100W
This product adopts a TO-247 package with a directly exposed ceramic substrate structure and is used with dedicated mounting spring clips in conjunction with a heat sink. It offers high rated power and pulse load capability.
Rated power: 100W when the center temperature of the base plate is 25°C
Standard TO-247 molded package with exposed ceramic substrate
M3 screw mounting, combined with special mounting spring clips, enhances thermal conductivity of the resistor
Two pin length specifications; refer to the dimensional drawing for details:
LXP100: Standard version
LXP100L: Long-pin version
For pulse load capability, refer to "EBG Power Resistor Pulse Electrical Characteristics"
Technical Characteristics
Parameter
Specification / Value for RTP100
Resistance Range
0.2 ~ 1M
Resistance Tolerance
±1% to ±10% (±0.5% available upon request)
Temperature Coefficient
As low as ±50 ppm/°C (25°C to 105°C)
Dielectric Withstanding Voltage
1800 VAC
Insulation Resistance
Min. 10 G
Momentary Overload
2x rated power, but not exceeding 1.5x maximum continuous working voltage, for 5 sec. R ±(0.3%R + 0.001)
Life
2000 hours at rated power per MIL-R-39009D, R ±(1.0%R + 0.001)
Moisture Resistance
MIL-STD-202, Method 106, R ±(0.5%R + 0.001)
Thermal Shock
MIL-STD-202, Method 107, Condition F, R ±(0.3%R + 0.001)
Terminal Strength
MIL-STD-202, Method 211, Condition A, 2.4 N tension test, R ±(0.2%R + 0.001)
High Frequency Vibration
MIL-STD-202, Method 204, Condition D, R ±(0.2%R + 0.001)
Operating Temperature Range
-55°C to +175°C
Lead Material
Tin-plated anti-oxidation copper wire
Max. Torque for M3 Screw
0.9 N.m
==========
Accuracy : 1%
Resistance Tolerance : 1%-5%
Type : Fixed Resistor
