General information
Type
CPU / Microprocessor
Market segment
Desktop
Family
A II X4
Model number ?
645
CPU part numbers
ADX645WFK42GM is an OEM/tray microprocessor
ADX645WFGMBOX is a boxed microprocessor with fan and heatsink
Stepping codes
AADHC ADCADHC ADCADIC ADNADHC ADNADIC AD
Frequency ?
3100 MHz
Bus speed ?
667 MHz Memory controller
One 2000 MHz 16-bit HyperTransport link
Clock multiplier ?
15.5
Package
938-pin organic micro-PGA
Sockets
Socket AM2+
Socket AM3
Weight
1.4oz / 39.5g (CPU)
12.7oz / 358.7g (box)
Fan/heatsink
FHSA7015B-1088
Architecture / Microarchitecture
Microarchitecture
K10
Processor c ?
Propus
c stepping ?
BL-C3
CPUID
100F53
Manufacturing process
0.045 micron silicon-on-insulator (SOI) technology
Die
169mm2
Data width
64 bit
The number of CPU cores
4
The number of threads
4
Floating Point Unit
Integrated
Level 1 cache size ?
4 x 64 KB 2-way set associative instruction caches
4 x 64 KB 2-way set associative data caches
Level 2 cache size ?
4 x 512 KB 16-way set associative caches
Level 3 cache size
None
Cache latency
3 (L1 cache)
15 (L2 cache)
Multiprocessing
Uniprocessor
Extensions and Technologies
MMX instructions
Extensions to MMX
3DNow! technology
Extensions to 3DNow!
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSE4a ?
EVP / Enhanced a Protection ?
Low power features
Cool'n'Quiet 3.0
CoolCore Technology ?
Dual Dynamic Power Management ?
c C1 and C1E states
Package S0, S1, S3, S4 and S5 states
Integrated peripherals / components
Integrated graphics
None
Memory controller
The number of controllers: 1
Memory channels: 2
Channel width (bits): 72
Supported memory: DDR2-1066, DDR3-1333
DIMMs per channel: up to 2
Maximum memory bandwidth (GB/s): 21.3
Other peripherals
HyperTransport 3 technology
Electrical / Thermal parameters
V c ?
1.05V - 1.4V
Maximum operating temperature ?
71°C
Thermal Design Power ?
95 Watt
