Hardware Specification:
CPU: Rockchip RK3588S, Quad-core ARM Cortex-A76 (up to 2.4GHz) & Quad-core Cortex-A55 (up to 1.8GHz)
GPU: Mali-G610 MC4, compatible with OpenGLES 1.1, 2.0, and 3.2, OpenCL up to 2.2 and Vulkan1.2
VPU: 8K@60fps H.265 and VP9 decoder, 8K@30fps H.264 decoder, 4K@60fps AV1 decoder, 8K@30fps H.264 and H.265 encoder
NPU: 6TOPS, supports INT4/INT8/INT16/FP16
Memory: 4GB/16GB/32GB 64-bit LPDDR5 @2400MHz
Storage: 1 x MicroSD Slot (up to SDR104 mode); 1 x eMMC module socket (HS400 mode); 1 x M.2 M-Key 2280 connector for SSD (PCIe 2.1 x1)
Connectivity: 1 x Native Gigabit Ethernet (RTL8211F chip); 1 x M.2 E-Key 2230 connector (PCIe 2.1 x1 & USB 2.0 Host for Wi-Fi/BT)
Video Input: 1 x 4-lane MIPI-CSI V1.2; 1 x 4-lane MIPI-CSI D/C PHY
Video Output: 1 x Standard HDMI output (HDMI 2.1, 2.0, 1.4 compatible, up to 7680 x 4320 @ 60Hz); 2 x 4-lane MIPI-DSI (MIPI DPHY 2.0 or CPHY 1.1)
USB: 1 x USB 3.0 Type-A; 2 x USB 2.0 Type-A
Audio: 1 x 3.5mm jack for stereo headphone output; 1 x 2.0mm PH-2A connector for analog microphone input
Pin-header: 30-pin 2.54mm header connector (GPIO, SPI, I2C, UART, PWM, etc.); 3-pin Debug UART (1.5Mbps)
LED & Buttons: 1 x SYS LED (Red), 1 x LAN LED (Green); MASK, Reset, Recovery, and Power buttons
Others: RTC Battery connector (HYM8563TS); Fan Connector (ZH1.5-2A) x 1, 5V; Operating Temp: 0°C to 70°C
Power: 1 x USB-C (6V-20V), supports PD and DC (65W power supply recommended for full load)
OS Support:
FriendlyWrt 21.02 / 24.10
FriendlyCore 20.04 / OpenMediaVault 8.0.6
Android 14 Tablet / Android 14 TV
Debian 11 Desktop (XFCE) / Debian 13 Core
Ubuntu 20.04 Desktop (LXQT) / Ubuntu 24.04 Desktop (GNOME)
Proxmox VE / Alpine-Linux / Buildroot
Kernel version: Linux-6.1-LTS / U-boot
Dimension:
PCB: 8 Layer
Weight: 52g (without Case) / 252g (with Metal Case)
Dimension: 62x90x1.6mm (PCB) / 68x94.5x30mm (with Metal Case)
