Specifications:

▲ Camera Certificate: FCC; Number: CTE22070801501
▲ Sensor Type: 1 million pixel color image CMOS sensor;
▲ Photosensitive size: 1/4.5″
▲ Effective pixels: 1280(H)x720(V)
▲ Minimum Illumination: 0.5 Lux
▲ White Balance: Auto
▲ Automatic Gain Control AGC: Automatic
▲ Backlight compensation: Yes
▲ Noise reduction: 2D DNR, 3D DNR
▲ SNR: >52dB(AGC OFF)
▲ Video format: AHD 720P@30FPS NTSC /CVBS 960H/D1
▲ Video Out: 1.0 Vp-p / 75 ohms, Analog High-Definition image
▲ Video Output format: AHD/CVBS
▲ Reverse Scale Line: Show/Do not show
▲ Gamma correction: 0.45
▲ Waterproof Rate: IP68
▲ Working voltage: DC 8V-24V
▲ Working current: 22mA@12V
▲ Power: 0.27W
▲ Working temperature: -30℃～+85℃ (-22F-185F)
▲ Video Cable: 6+1 =7 Meters (20+3 =23 Feet)
▲ Connector: RCA output / Or customization
▲ Compatible with: Any Car.

Notes:
（navigation system/stereo/head unit/monitor are all represented by monitor in the text）
▲ After cutting any color wire loop, please power on again!
▲ It is a general product for monitor with RCA input. If your monitor has RCA input, you can connect.
▲ This is a universal accessory. If your monitor only supports dedicated cameras, then our cameras may not work with your monitor (please contact the monitor dealer before purchasing, check the monitor manual, etc. for more restrictions).
▲ If connect this car rear view camera to a factory/non-universal radio, please separately order a suited harness to complete installation, because different radio need different harness to work together, you can send the your monitor details and we will help you find the adapter and how to set it up.
▲ This backup car camera doesn't fit sucked type dash cam and mirror dash cam, because these dash cam have different connectors and PIN definition, even some of them with same 4 PIN connector.
