Overview

The RGB Matrix Adapter Board (E) is a high-performance LED panel driver board designed exclusively for the ESP32-S3-DevKitC-1 and ESP32-DevKitC V4 development boards. With optimized
signal transmission and power management, it provides a reliable foundation for building RGB LED matrix displays.

The adapter includes a standard HUB75 connector and dual VH-4P (3.96mm pitch) power connectors, making it compatible with common RGB LED matrix panels. This allows developers to easily
build projects that display text, images, graphics, and animations.

Power stability is a key design feature. The board supports dual input options: USB Type-C (5V/4A) and DC-044 barrel jack (5V/8A), delivering consistent and safe operation even for high-current
RGB panels.

This product is an expansion/compatibility board designed to work with Espressif ESP32-S3 and ESP32-DevKitC development modules. It supplies USB Type-C power, pin access and convenient connectivity
for prototyping and embedded development.
Important: this item is a development accessory and not a pre-programmed consumer wireless device. Any wireless or radio functions are provided by the installed ESP32 module and require firmware
configuration (ESP-IDF or Arduino IDE). Radio certification and regulatory compliance (e.g., FCC) depend on the specific ESP32 module and how the product is used. Please consult the module manufacturer's
documentation and our Wiki guide before use: https://seengreat.com/wiki/186/

Package Contents

1. RGB Matrix Adapter Board x1
2. 40pin header receptacle x1
3. Signal wire x1
4. Power supply wire x2
5. Accessory pack x1
6.Type-C cable x1
