Specification
Facial Recognition
Facial Detection and Analytics: Face picture comparison, human face capture, face picture search
Face Picture Library: Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4MB, total capacity ≤ 1 GB)
Facial Detection and Analytics: Performance 1-ch human face capture
Face Picture Comparison: 4-ch face picture comparison alarm
Motion Detection 2.0
Human/Vehicle Analysis: 8-ch
Video and Audio
IP Video Input: 8-ch
Incoming Bandwidth: 80 Mbps
Outgoing Bandwidth: 80 Mbps
HDMI Output: 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
VGA Output: 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode: HDMI/VGA independent output
CVBS Output: N/A
Audio Output: 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding
Decoding Format: H.265/H.265+/H.264+/H.264
Recording Resolution: 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback: 8-ch
Decoding Capability: AI on: 1-ch@12 MP (30 fps)/1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps) AI off: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)
Stream Type :Video, Video & Audio
Audio Compression :G.711ulaw/G.711alaw/G.722/G.726/AAC
Network
Remote Connection :128
Network Protocol :TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
Network Interface: 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interface: 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power: ≤ 75 W
Standard :IEEE 802.3af/at
Auxiliary Interface
SATA: 1 SATA interface
Capacity: Up to 10 TB capacity for each HDD
USB Interface: Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
Alarm: In/Out N/A (4/1 is optional)
General
Power Supply: 48 VDC, 1.875 A
Consumption: ≤ 10 W (without HDD, and PoE off)
Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity :10% to 90%
Dimension: (W × D × H) 320 mm × 240 mm × 48 mm (12.6"× 9.4" × 1.9")
Weight: ≤ 1 kg (without HDD, 2.2 lb.)
Certification
FCC: Part 15 Subpart B, ANSI C63.4-2014
CE :EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
