10 hp 3600 RPM 215T Frame 208-230/460V TEFC Nidec Electric Motor # HD10P1E in Kuwait 10 hp 3600 RPM 215T Frame 208-230/460V TEFC Nidec Electric Motor # HD10P1E in Kuwait

10 hp 3600 RPM 215T Frame 208-230/460V TEFC Nidec Electric Motor # HD10P1E

KWD 328.500

Brand
Nidec
Category
Electric Motors
Weight
63.5 kg
1 +

Special Features

  • 10 hp 3600 RPM, 23.5/11.8 amps 208-230/460 Volts Three Phase Motor
  • NEMA 215T frame Keyed Shaft 1-3/8" x 3 3/8"
  • TEFC; Service Factor: 1.15, Overload protection = None
  • Reversible, Rigid Base Mount, Ball Bearings, Class F Insulation
  • "C" Dimension 19.6"; Year Manufacture Warranty

Description

Hostile duty, premium efficient, world motor, cast iron frame. Corrosion resistant mill & chemical duty paint, stainless steel nameplate (with CE mark) & zinc plated hardware. Steel fan cover & conduit box, condensation drains with plastic plugs. Suitable for 20:1 variable torque; 5:1 constant torque on inverter power. Motor has a rigid base mount with a keyed shaft. Continuous Duty. 40C Ambient Temp. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. Model GE02, Replaces H10P1D
