مميزات خاصة

[WHAT YOU GET & TUBE SUPPORT] Contents 1 audio transformer. Supports 6P1, 6P14 and 6P6 tubes for single-ended 5W applications, making it suitable for restoration, custom builds and experimental amplifiers.
[DESIGNED FOR SIGNAL INTEGRITY] Stable 12H inductance combined with the single-ended topology helps preserve audio detail and control low-frequency response in small tube circuits.
[MULTI-OUTPUT OPTIONS] Secondary impedance choices of 0, 4 ohm and 8 ohm give you the flexibility to match vintage drivers, modern speakers or multi-amp setups.
[SPACE-SAVING FRAME] 19 x 25 mm frame size with a compact overall footprint of 60 x 55 x 50 mm enables neat placement on chassis and leaves room for other components; mounting holes spaced 72 mm.
[MEASURED PARAMETERS FOR TUNING] Initial impedance 5K, primary DC resistance 315 ohm and 12H inductance provide clear specifications to aid fine-tuning and crossover design work.

وصف

Features:
*5K Single-Ended Output: Designed for 6P1, 6P14, and 6P6 tubes, delivering 5W power for optimal audio amplification.
* FOR Construction: Made with - materials for long-lasting performance in tube audio device setups.
*Versatile Impedance: Features secondary outputs of 0-4Ω-8Ω to accommodate various speaker for configurations.
*Compact Design: Measures 60x55x50mm for easy integration into audio device builds without sacrificing performance.
*Stable Inductance: Provides 12H inductance value for consistent audio signal transmission and minimal distortion.

Specifications:
*Product Name:Output cow
*Material: material
*Color:black
*Size:60 * 55 * 50 mm
*Frame Size: 19x25 (Latch Width: 19, Stack Thickness: 25)
*Initial Impedance: 5KΩ
*Secondary Impedance: 0-4Ω-8Ω
*Inductance: 12H
*Primary DC Resistance: 315Ω
*Mounting Hole Distance: 72 m

Package Content:
1*Audio Transformer
