Duty Torque Sensor for Precise Measurement
Powerful Capacity: This torque sensor offers an impressive capacity of ±10000N.m, making it perfect for duty industrial applications where high - torque measurement. The display range of - 99999 to 99999 provides comprehensive and clear readings.
Speed - related Capabilities: With a speed capacity of 15000rpm, it can handle a wide range of rotational speeds. The diverse speed signal options, including 120/60/10rpm, 4 - 20mA, 0 - 20mA, 0 - 5V, and 0 - 10V, ensure easy integration with various systems.
High - precision Metrics: Non - linearity and hysteresis are both 0.5%F.S., repeatability is 0.2%F.S., and creep within 30 minutes is 0.03%F.S/30min. The zero balance is ±2%F.S., and the temperature effect on zero is 0.01%F.S./10, guaranteeing accurate measurements even in varying conditions.
Dynamic Performance: The maximum torsion angle is 2.60×10rad(0.149°), the moment of inertia is 0.38kgcm, the natural of rotor vibration is 19.4kHz, and the torsion constant is 3.85×10N.m/rad. These parameters ensure stable performance during dynamic operations.
Durable Build: Constructed from stainless steel, it provides durability and resistance, ensuring long - term reliable use.
Efficient Operation: Equipped with a 5*3m cable for easy installation, it has a response of 1kHz and a response time of 0.6ms(50%). The acquisition speed of 550/1200/m enables quick data collection. It can operate within a temperature range of - 10 to 50 and a humidity of 0 - 85%RH, making it highly adaptable to different working environments.
Specification
Capacity
±10000N.m
Display Range
-99999-99999
Speed Capacity
15000rpm
Maximum torsion angle
2.60*10rad(0.149°)
Speed Signal
120/60/10/rpm, 4-20mA, 0-20mA, 0-5V, 0-10V
Moment of inertia
0.38kgcm
Non-Linearity
0.5%F.S.
Natural of rotor vibration
19.4kHz
Hysteresis
0.5%F.S.
Torsion constant
3.85x10N.m/rad
Repeatability
0.2%F.S.
Stability per year
0.3%/year
Creep(30min)
0.03%F.S/30min
Material
Stainless Steel
Zero Balance
±2%F.S.
Working voltage
DC 24V 0.2A
Temp Effect on Zero
0.01%F.S./10
Safe Overload
200%
Response
1kHz
Current consumption
Response time
0.6ms(50%)
Cable Specifications
5*3m
Acquisition Speed
550/1200/m
OperatingTemp Range
-10-500-85%RH
Load resistance
2k
is_customized : Yes
Material : Metal
Origin : Mainland China
Model Number : DYN-200 PRO
